Ottawa's residential setbacks now come from Table 801B of Zoning By-law 2026-50, keyed to the subzone letter after a lot's N zone.
Front yards run from 3 metres in subzone A to 6 metres in subzones D, E and F. The rear yard is 25% of the lot depth, at least 6 metres and never required to exceed 7.5 metres, though in subzones A to C that rule is still under appeal.
The combined interior side yards range from 1.8 metres in subzone A to 9 metres in subzone F, and no single side yard can be under 0.6 metres in subzones A and B or 1.2 metres elsewhere. While the City applies both the new by-law and By-law 2008-250, the stricter setback of the two governs.
The most common Ottawa renovation question we get is some version of "how close can I build to the property line?" The honest answer takes a paragraph, not a number, because it depends on which line, which zone, and what is already there. But the rules are knowable, and most projects can be designed inside the envelope without a variance.
Here is how Ottawa setbacks actually work, the standard numbers for each zone, and the workarounds when the standard numbers do not fit.
What a Setback Is
A setback is the minimum required distance from a property line to a building. It is the negative space the by-law forces around your house. Together with height limits and lot coverage, setbacks define the building envelope.
Section 64 of Zoning By-law 2008-250 defines four setbacks for every Ottawa lot:
- Front yard setback: distance from the front lot line to the front face of the building
- Rear yard setback: distance from the rear lot line to the rear face of the building
- Interior side yard setback: distance from each interior side property line to the side face
- Corner side yard setback: on a corner lot, distance from the flanking street to the building (replaces one of the interior side setbacks)
Setbacks are measured horizontally, at the closest point of the building to the lot line. The closest point is usually the wall face, but cantilevered overhangs, bay windows, decks, and chimneys can become the closest point if they project further than the wall.
The Standard R1 Numbers
For most R1 (single-detached) zones in Ottawa:
- Front yard: 6.0m typical, 4.5m to 7.5m depending on subzone
- Interior side yard: 1.2m on each side, with a combined minimum of 3.0m on most lots over 12m wide
- Rear yard: 7.5m typical, sometimes 6.0m on shallow lots
- Corner side yard: 3.0m to 4.5m to the flanking street
R2 (semi-detached, duplex) typically has tighter side setbacks (sometimes 1.0m or even 0m on the shared wall) and similar front/rear.
R3 (row house) sets minimum end-unit side setbacks of 1.5m, with rear typically 6.0m.
R4 (low-rise apartment) varies by sub-zone but generally has larger setbacks because the buildings are taller and serve more units.
Rural Residential and Village zones have larger numbers across the board: front 9m, side 4.5m to 7.5m, rear 9m to 30m, depending on lot size and septic system requirements.
Setbacks by Subzone Under By-law 2026-50
The new by-law, enacted 2026-03-11 and mostly in force since the Ontario Land Tribunal's decision of 2026-07-02, replaced R1 to R5 with N1 to N6 zones. The number sets height and density. The letter, A to F, sets the yards, with A the most urban lot pattern and F the most suburban. Table 801B gives the minimums for each letter:
| Subzone | Front | Side yards, total | Corner side | Lot width |
|---|---|---|---|---|
| A | 3 m | 1.8 m | 3 m | 6 m |
| B | 3 or 4.5 m | 1.8 m | 3 m | 7.5 m |
| C | 4.5 m | 2.4 m | 3 m | 10 m |
| D | 6 m | 3 m | 4.5 m | 15 m |
| E | 6 m | 3.6 m | 4.5 m | 18 m |
| F | 6 m | 9 m | 6 m | 24.5 m |
Subzone B's front yard is 3 metres in the Suburban area and 4.5 metres elsewhere. The corner side column is the exterior side yard on a corner lot.
A 24 metre deep lot works out to a 6 metre rear yard and a 30 metre lot to 7.5 metres. Past 30 metres the cap holds it at 7.5, where a straight 25% of a 40 metre lot would have asked for 10, and that leaves more of a deep lot open to a rear addition.
Subzones A and B in the Suburban area use a flat 6 metres. The City's memo to Council of 2026-07-07 lists the rear yard setbacks in subzones A to C as still under appeal and not in force, so confirm the rear yard for a lot in those subzones with the City before drawing.
Front yards next to older houses
Section 802 lets a front yard shrink to match the street. If a neighbouring house legally sits closer to the street than the minimum, the front yard can drop to the average of the two neighbours' front yards, or to the one neighbour's setback where only one abutting lot has a building, but never below 1.5 metres.
Exterior side yards work the same way. This does the job the established setback rule below did under By-law 2008-250.
Corner lots and garages
On a corner lot the rear yard can drop to 1.2 metres if an interior yard is kept beside it, at least 30% of the lot width wide and as deep as the normal rear yard. In N1 to N4, where every unit faces the longer street, that street line counts as the front and the rear yard minimum is 4 metres.
In the Suburban area, a garage or carport door must sit at least 5.7 metres back from an existing or planned sidewalk (Section 802).
What may sit inside a setback
Section 204 sets the projections. A heat pump, air conditioner or permanent generator beside a house can project up to 1 metre into a yard but must stay 0.3 metres from the lot line. An awning or canopy must stay 0.6 metres from the lot line and can reach 2 metres into an interior side yard.
In a rear yard, a shed or other accessory building needs 0.6 metres from the side and rear lot lines (Section 202). A coach house needs the same 0.6 metres in the urban area, plus 1.2 metres from any other building (Section 701).
Sources: City of Ottawa, Zoning By-law 2026-50, Part 8, Neighbourhood Zones, Part 2, General Provisions and Part 7, Housing Provisions, and the City's memo to Council on the appeals (2026-07-07). All read 2026-10-05.
The Established Setback Rule
This is the rule most homeowners do not know about, and it solves more problems than any other.
By-law 2008-250 contains a "mature neighbourhood" overlay that applies to most older urban Ottawa neighbourhoods (Westboro, Hintonburg, Glebe, Centretown, New Edinburgh, Old Ottawa South, Manor Park, parts of Sandy Hill, Lowertown, etc.).
In those neighbourhoods, the front yard setback is determined not by a fixed number but by the average front setback of the houses on the same side of the street within 75m of your lot, excluding outliers.
So if every neighbouring house sits 4.5m back from the street and the standard R1 setback would be 6.0m, you build to 4.5m, matching the neighbours, with no variance required. The rule is designed to let infill construction match the existing streetscape.
The reverse is also true. If every neighbour sits 9m back, you cannot push your new build to 6.0m; the established setback governs.
How to find your established setback
Order a topographic survey of your lot showing the front faces of the four to six closest houses on each side. Your designer takes the measurements off the survey, calculates the average, and uses that as your setback. The City zoning examiner will independently verify it during permit review.
What Counts as the Building Face
The setback is measured to the closest point of the building, but the by-law allows a few elements to project into the setback without violating it:
- Eaves and roof overhangs may project up to 0.6m into any setback
- Cornices, sills, belt courses, and decorative trim may project up to 0.45m
- Bay windows may project up to 0.6m, provided the bay is no more than 4m wide
- Chimneys may project up to 0.6m
- Uncovered decks at grade may extend up to 1.5m closer to a side or rear lot line than the building face, in most R1 zones
- Air conditioning units and heat pumps may sit up to 0.6m into the side setback
- Steps and ramps may project up to 1.5m into front or rear setbacks
- Wheelchair ramps have a separate, more generous projection allowance
These small projections add up. A 0.6m eave plus a 0.6m bay window means a wall that sits 1.2m from the property line has its outermost element only 0.6m from the line, which often complies with the side setback.
Corner Lot Specifics
On a corner lot, you have two yards facing streets and two yards facing other property:
- Front yard on the street where your address is
- Corner side yard on the flanking street (typically 3.0m to 4.5m)
- Interior side yard on the property-line side (1.2m typical R1)
- Rear yard on the back property line (7.5m typical R1)
Corner lots also have a visibility triangle: a 6m by 6m triangle at the corner where no structure may block driver sight lines. This applies to fences, walls, and certain landscape elements as well as buildings.
The Reduced Side Yard Variance
The most common minor variance application in Ottawa is for a reduced side yard setback to accommodate an addition. The by-law calls for 1.2m; the project needs 0.9m or 0.6m. The variance approval rates from Committee of Adjustment data:
- 1.2m down to 0.9m: approved roughly 90% of the time
- 1.2m down to 0.6m: approved roughly 75% of the time
- 1.2m down to 0.3m: approved roughly 40% of the time, often with conditions
- Side yard down to 0m (zero-lot-line): rare for R1, common for R2 semi-detached attaching to a neighbour
The Building Code adds its own rule: at any side setback under 1.2m, the wall must be a 45-minute fire-rated assembly with limited window area (Section 9.10.14 of the OBC). Going below 0.6m triggers stricter fire requirements that often make the construction more expensive than the variance saves.
Rear Yard Setbacks and Decks
Rear yard setbacks (7.5m typical R1) define the buildable rear envelope. Most rear additions in Ottawa are constrained by this, not by lot coverage.
An uncovered deck under 600mm above grade does not need to respect the full 7.5m. It can extend much closer to the rear line, often to 3m or even 1.5m depending on the zone, because by-law treats uncovered decks differently than principal-building footprint.
This is why many Ottawa rear-yard plans are: enclosed addition pushed to 7.5m, then a generous open deck out to 4m or 5m setback, then lawn and garden beyond.
"You don't fight rear yard setback. You design with it. The 7.5m envelope plus a 22-square-metre uncovered deck is the formula that works on 80% of Ottawa rear additions."
Coach House and Garden Suite Setbacks
Detached additional dwelling units (coach houses, garden suites) created under Bill 23 have their own setback rules in By-law 2008-250:
- 1.0m to 1.2m setback from the rear and side property lines
- Maximum 6.5m height to the peak of the roof
- Maximum 80 m² gross floor area
- 1.5m setback from the principal dwelling on the same lot
These are friendlier than the principal-building setbacks because the policy goal is to encourage these units. Lot coverage still applies, however.
Heritage Setbacks
For Part IV designated properties or those inside Heritage Conservation Districts, the heritage rules may impose additional setback constraints to preserve the streetscape rhythm. The Glebe HCD Plan, for example, requires new construction to match the established front setback of the block, often within a tighter tolerance than the general by-law allows.
Practical Setback Workflow
- Find your zone code on the City zoning map (geoOttawa)
- Read the setback table for that zone in By-law 2008-250
- If you are in a mature neighbourhood, get a topographic survey to establish the average front setback
- Check whether your property is in a Heritage Conservation District
- Check for any zoning exceptions registered on your specific lot (the City lists these in the zoning report)
- Design within the resulting envelope
- If the design needs to push past the limit by a small margin, file a minor variance (application fees, planning rationale, and an 8 to 12 week timeline)
Our free 48-hour lot feasibility review covers all six steps. We pull the zoning report, identify the established setback if your address is in a mature overlay, flag any heritage overlay, and tell you exactly what your buildable envelope is. From there, you and your designer can plan with certainty.
If your project requires a variance, our permits team handles the Section 45 application, planning rationale, and Committee hearing representation. Call 613-862-4555 to schedule a setback check.
Frequently asked questions
What are the standard setbacks for an R1 lot in Ottawa?
Most R1 single-detached zones in Ottawa set a front yard of about 6.0 m, ranging from 4.5 m to 7.5 m by subzone. Interior side yards are 1.2 m on each side, with a combined minimum of 3.0 m on most lots over 12 m wide. The rear yard is typically 7.5 m, sometimes 6.0 m on shallow lots, and a corner side yard runs 3.0 m to 4.5 m.
How is the front setback set in older Ottawa neighbourhoods?
In older Ottawa neighbourhoods under the mature neighbourhood overlay, such as Westboro, the Glebe and New Edinburgh, the front setback is the average front setback of houses on the same side of the street within 75 m, excluding outliers. If neighbours sit 4.5 m back, you build to 4.5 m with no variance. A topographic survey of the nearest houses gives the measurements for that average.
Can eaves, bay windows and steps project into a setback?
Several elements can project into an Ottawa setback without breaking it. Eaves, chimneys and bay windows up to 4 m wide may project up to 0.6 m. Cornices, sills and decorative trim may project 0.45 m. Air conditioners and heat pumps may sit 0.6 m into the side setback, and steps and ramps may project up to 1.5 m into front or rear setbacks.
How likely is a reduced side yard variance to be approved?
A reduced side yard setback is the most common minor variance in Ottawa. Going from 1.2 m to 0.9 m is approved roughly 90% of the time, to 0.6 m roughly 75%, and to 0.3 m roughly 40%, often with conditions. Under 1.2 m, OBC 9.10.14 also requires a 45-minute fire-rated wall with limited window area, and below 0.6 m the fire requirements get stricter.
How close to the rear lot line can a deck be built?
An uncovered deck under 600 mm above grade does not have to respect the full 7.5 m rear yard setback that applies to the house. Depending on the zone, it can often extend to 3 m or even 1.5 m from the rear line. That is why many Ottawa rear plans push the enclosed addition to the 7.5 m line, then run an open deck beyond it.
